LM317HVK STEEL - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LM317HVK STEEL
Manufacturer

TI
ChipWorker Part#

CW99230596
Category

Voltage Regulator
Package

TO-3-2
Description

LDO Regulator Pos 1.2V to 57V 1.5A 3Pin(2+Tab) TO-3 Tray
Documentation

Datasheet

LM317HVK STEEL Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LM317HVK STEEL Specifications

Attribute	Attribute Value

Part Number	LM317HVK STEEL
Manufacturer	TI
ChipWorker Part#	CW99230596
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-3-2
Number of Outputs	1 Output
Output Voltage	1.2V ~ 57V
Output Current	1.5 A
Quiescent Current	60.0 µA
Output Capacitor Type	Ceramic
voltage rating	2.25 V
Number of Regulated Outputs	1 Output
Input Voltage (Max)	60 V
Input Voltage (Min)	4.2 V
Output Current (Max)	1.5 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	0 ℃
Input Voltage	4.2V ~ 60V
	expand all
Operating Temperature	0℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Product Description

This standard LM317HVK STEEL linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. This voltage regulation device"s single output can produce a current up to 1.5 A. It only needs a voltage of at least 4.2 V while not exceeding 60 V to effectively power your circuit. With an adjustable output that has a voltage of 1.2 to 57 V, this is power management at its best. Using a load regulation of 0.5% and line regulation of 0.04%/V is needed for a programmable DC power supply. The component will be shipped in tray format. This voltage regulation device has an operating temperature range of 0 °C to 125 °C. Its polarity is positive.
