LM555CN
Manufacturer

Fairchild
ChipWorker Part#

CW5695533
Category

Clock Chip, Timing IC
Package

DIP-8
Description

FAIRCHILD SEMICONDUCTOR LM555CN Timer, Oscillator & Pulse Generator IC, TTL Compatible, Astable, Monostable, 4.5V to 16V, DIP-8
Documentation

Datasheet
Ships from

Moscow
Наличие

49 pcs In Stock
Estimated Price

$ 0.13

Buy LM555CN

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LM555CN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LM555CN Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LM555CN
Manufacturer	Fairchild
ChipWorker Part#	CW5695533
Category	Clock Chip, Timing IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	4.50V (min)
Current Rating	15.0 A
Input Voltage (DC)	15.0V (max)
Output Current	≤200 mA
Supply Current	7.5 mA
Number of Positions	8 Position
Power Dissipation	0.6 W
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	600 mW
Supply Voltage	4.5V ~ 16V
Supply Voltage (Max)	16 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	10.15 mm
Size-Width	6.35 mm
Size-Height	3.15 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The LM555CN is a highly stable Controller/Single Timer, capable of producing accurate timing pulses. With monostable operation, the time delay is controlled by one external resistor and one capacitor. With a stable operation, the frequency and duty cycle are accurately controlled with two external resistors and one capacitor.
High Current Drive Capability (200mA)
Adjustable Duty Cycle
Temperature Stability of 0.005%/°C
Timing From µSecond to Hours
