MA330031 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MA330031
Manufacturer

Microchip
ChipWorker Part#

CW40919736
Category

Microprocessor Development Kit
Package

TQFP
Description

Daughter Cards & OEM Boards 32Bit MCU 512KBFlash 128KB RAM, 80MHz
Documentation

Datasheet

MA330031 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MA330031 Specifications

Attribute	Attribute Value

Part Number	MA330031
Manufacturer	Microchip
ChipWorker Part#	CW40919736
Category	Microprocessor Development Kit
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	TQFP
Core Architecture	dsPIC
Core Sub-Architecture	dsPIC33
	expand all
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	5A002.a.1

Product Description

MA330031 is a Internal Op amp motor control plug in module (PIM). This plug in module is designed to demonstrate the capabilities of the dsPIC33EP256MC506 motor control device using internal op amps with development boards, such as the dsPICDEM MCLV-2 development board (DM330021-2) and the dsPICDEM MCHV-2 development board (DM330023-2), which support 100 pin PIM interfaces. The dsPIC33EP256MC506 is a high performance, 16bit digital signal controller (DSC) in a 64 pin TQFP package. This device is equipped with three internal op amp/comparators and one dedicated analog comparator. To operate this PIM with the dsPICDEM MCLV-2 and dsPICDEM MCHV-2 development boards, please insert the Internal op amp configuration board into the header, J4 (for the dsPICDEM MCHV-2 development board) or header, J14 (for the dsPICDEM MCLV-2 development board). This PIM can be used to evaluate the dsPIC33EPxxxMC50x, dsPIC33EPxxxMC20x, and PIC24EPxxxMC20x devices.
Peripheral trigger generator (PTG) for scheduling complex sequences
Modified Harvard architecture
Two 40bit accumulators with rounding and saturation options
Single cycle shifts for up to 40bit data
Single cycle multiply and accumulate
24bit wide instructions
16x16 fractional multiply/divide operations
Up to three PWM pairs with independent timing
Programmable fault inputs
Flexible trigger configurations for ADC conversions
Do not connect non isolated oscilloscope probes to this PIM while using it with dsPICDEM MCHV-2. Use a high voltage differential probe. Failure to heed this warning could result in hardware damage.
This PIM can not be used with original MCHV [DM330023] or MCLV [DM330021] development boards. Use the external op amp PIM [MA330031-2] to use the dsPIC33EP256MC506 with original MCHV or MCLV boards.
