MC33262 - Multicomp

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MC33262
Manufacturer

Multicomp
ChipWorker Part#

CW45137407
Category

Heatsinks, Heat Sink
Package

TO-218
Description

MULTICOMP MC33262 Heat Sink, Square, PCB, Extruded, TO-218, TO-220, 12.9℃/W, 38.1mm, 16.6mm, 16.26mm
Documentation

Datasheet

MC33262 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MC33262 Specifications

Attribute	Attribute Value

Part Number	MC33262
Manufacturer	Multicomp
ChipWorker Part#	CW45137407
Category	Heatsinks, Heat Sink
Documentation	Datasheet
Mounting Style	Through Hole
Case/Package	TO-218
Thermal Resistance	12.9 ℃/W
	expand all
Size-Length	16.3 mm
Size-Width	16.6 mm
Size-Height	38.1 mm
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The MC33262 is a 16.26 x 38.1 x 18.29mm flat back vertical mounting extruded Heat Sink with solderable fixing pins. This Small PCB footprint heat sink is made of aluminium with black anodized finish. It can be mounted through mounting holes and is suitable for use with a single TO2-18/TO-220 devices.
