MCP41010-I/P ,Digital Potentiometer IC - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

154 points

Part No

MCP41010-I/P
Manufacturer

Microchip
ChipWorker Part#

CW2968489
Category

Digital Potentiometer IC
Package

PDIP-8
Description

Pot; Digital; Rest 10KΩ; Digital; 256POS; 8Pins; 1CH; Pkg DIP
Documentation

Datasheet
Ships from

Moscow
Наличие

174 pcs In Stock
Estimated Price

$ 2.15

Buy MCP41010-I/P

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MCP41010-I/P Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MCP41010-I/P Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MCP41010-I/P
Manufacturer	Microchip
ChipWorker Part#	CW2968489
Category	Digital Potentiometer IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	2.70V (min)
Capacitance Tolerance	±20 %
Supply Current	0.34 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	256 Position
Clock Speed	10.0MHz (max)
Resistance	10 kΩ
Resistance Tolerance	±20 %
Quiescent Current	10.0 nA
Bandwidth	1 MHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	9.78 mm
Size-Width	6.6 mm
Size-Height	3.68 mm
Operating Temperature	-40℃ ~ 85℃
Temperature Coefficient	±800 ppm/℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The MCP41010-I/P is a 256-position 1-channel Digital Potentiometer features 8-bit resolution (256 wiper steps) and an industry-standard SPI™ serial interface. The wiper position varies linearly and is controlled via the SPI interface. The MCP41010 has a resistance value of 10kR, outstanding AC and DC characteristics and consumes <1µA during static operation. Applications for the MCP41010 digital potentiometer includes LCD contrast control and programmable filters.
256 Taps for each potentiometer
SPI™ Serial interface (mode 0,0 and 1,1)
±1 LSB Maximum INL and DNL
Low power CMOS technology
1µA Maximum supply current in static operation
Multiple devices can be daisy-chained together
Shutdown features open circuits of all resistors for maximum power saving
ESD sensitive device, take proper precaution while handling the device.
