MDO3014 ,Oscilloscope - Tektronix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

74 points

Part No

MDO3014
Manufacturer

Tektronix
ChipWorker Part#

CW16472269
Category

Oscilloscope
Description

Oscilloscope, MDO3000 Series, 4Channel, 100MHz, 2.5GSPS, 10 Mpts, 4ns
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 11620.91

Buy MDO3014

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MDO3014 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MDO3014 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MDO3014
Manufacturer	Tektronix
ChipWorker Part#	CW16472269
Category	Oscilloscope
Documentation	Datasheet
Number of Channels	4 Channel
Sample Rate	2.50 GHz
Rise Time	3.5 ns
Bandwidth	100 MHz
Input Impedance	1 MΩ,50 Ω,75 Ω
Operating Temperature (Max)	55 ℃
Operating Temperature (Min)	-10 ℃
Supply Voltage (Max)	240 VAC
Input Voltage	300 V
	expand all
Size-Length	416.6 mm
Size-Width	147.4 mm
Size-Height	203.2 mm
Weight	4.2 kg
Packaging	Bulk
RoHS	RoHS Compliant
REACH SVHC Compliance	Contains SVHC
REACH SVHC Compliance Edition	2014/06/16

Similar & Replacement Parts

Similar products

Product Description

While the MDO3000 Series Mixed Domain Oscilloscope features other built-in instruments, it is first and foremost an oscilloscope. And a versatile one at that. The MDO3014 is packed with timesaving tools to help you discover, capture, search and analyze problems in your design faster than ever. While you may not know what the future holds, you can rest easy knowing your oscilloscope is ready for it. The MDO3014 is fully upgradeable, giving you the ability to add instruments and upgrade bandwidth as your test needs evolve. It"s the scope you need today that"s ready for tomorrow. They come with a built-in spectrum analyzer, featuring an independent RF acquisition system for the most accurate RF measurements, you can use one instrument as an oscilloscope and spectrum analyzer without compromising on performance.
Dedicated front panel controls enable easy zoom and navigation through 10 Mpoint records
250,000 waveforms per second acquisition rate
Built-in spectrum and protocol analyzer
Built in 4-digit voltmeter with AC+DC RMS, AC RMS, and DC measurements
Built-in logic analyzer with 16 digital channels
Integrated, upgradable arbitrary / function generator
Serial and parallel bus triggering and analysis
FastAcq™ high-speed waveform capture rate finds elusive signal anomalies quickly
Wave Inspector® Controls provide easy navigation and automated search of waveform data
33 automated measurements and waveform histograms for simplified waveform analysis
Small footprint and lightweight - Only 5.8 in. (147 mm) deep and 9.2 lb. (4.2 kg)
Front and rear USB host ports enable easy transfer of screen shots, settings, and waveform data
A video port on the instrument allows the display to be exported to an external monitor or projector
The standard 10/100 Ethernet port on the rear of the instrument enables easy connection to networks
