MJF6388G - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MJF6388G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW7889244
Category

BJT Transistor, BJT
Package

TO-220-3
Description

TO-220FP NPN 100V 10A
Documentation

Datasheet

MJF6388G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MJF6388G Specifications

Attribute	Attribute Value

Part Number	MJF6388G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW7889244
Category	BJT Transistor, BJT
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Voltage Rating (DC)	100 V
Current Rating	10.0 A
Output Voltage	100 V
Output Current	10 A
Number of Positions	3 Position
Input Current	1 A
Polarity	NPN
Power Dissipation	40 W
Breakdown Voltage (Collector to Emitter)	100 V
Thermal Resistance	62.5℃/W (RθJA)
Continuous Collector Current	10A
hFE Min	3000 @3A, 4V
hFE Max	15000
Input Power (Max)	2 W
DC Current Gain (hFE)	100
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	2000 mW
Input Voltage	5 V
	expand all
Size-Width	4.9 mm
Operating Temperature	-65℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99

Product Description

The Bipolar Power Transistor is designed for general-purpose amplifier and switching applications, where mounting surface of the device is required to be electrically isolated from the heatsink or chassis.
Features
---
|
Isolated Overmold Package, TO-220 Type
Electrically Similar to the Popular 2N6388, 2N6668, TIP102 and TIP107
100 VCEO(sus)
10 A Rated Collector Current
No Isolating Washers Required
Reduced System Cost
High DC Current Gain 1000 (Min) @ IC = 5.0 Adc
High Isolation Voltage (up to 4500 VRMS)
Case 221D is UL Recognized at 3500 VRMS: File #E69369
Pb-Free Packages are Available
