NTA1212MC Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | NTA1212MC | |
| Manufacturer | muRata | |
| ChipWorker Part# | CW58948166 | |
| Category | DC to DC Converter, DC/DC Converter | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 10 Pin | |
| Case/Package | SMD-18 | |
| Supply Voltage (DC) | 12.0 V | |
| Power Rating | 1 W | |
| Number of Outputs | 2 Output | |
| Input Voltage (DC) | 10.8V ~ 13.2V | |
| Output Voltage | ±12 V | |
| Output Current | 42.0 mA | |
| Flammability Rating | UL 94 V-0 | |
| Output Power | 1 W | |
| Isolation Voltage | 1 kV | |
| Input Voltage (Max) | 13.2 V | |
| Input Voltage (Min) | 10.8 V | |
| Input Voltage (DC Max) | 13.2 V | |
| Input Voltage (DC Min) | 10.8 v | |
| Output Current (Max) | 42mA, 42mA | |
| Input Power (Max) | 1 W | |
| Operating Temperature (Max) | 85 ℃ | |
| Operating Temperature (Min) | -40 ℃ | |
| Input Voltage | 10.8V ~ 13.2V | |
| expand all | ||
| Size-Length | 15.24 mm | |
| Size-Width | 7.7 mm | |
| Size-Height | 6.6 mm | |
| Operating Temperature | -40℃ ~ 85℃ | |
| Product Lifecycle Status | Active | |
| Packaging | Tube | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| REACH SVHC Compliance Edition | 2015/12/17 |
Similar & Replacement Parts
Similar products
Product Description
- The NTA1212MC is a 2-output 1W surface-mount isolated DC/DC Converter employs lead-frame technology and transfer moulding techniques to bring all of the benefits of IC style to hybrid circuitry. The device is suitable for all applications where high volume production is envisaged.
- Internal SMD construction
- Toroidal magnetics
- No heat sink required
- Multi-layer ceramic capacitors
- 1kVDC Isolation
- Power density 1.36W/cm³
- Footprint over pins 1.64cm²
- 75% Efficiency
- 89pF Isolation capacitance
- 7995µs Start-up time
