SK12BAW01 ,Keylock Switch, Switch KeyLock - NKK

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

47 points

Part No

SK12BAW01
Manufacturer

NKK
ChipWorker Part#

CW52015293
Category

Keylock Switch, Switch KeyLock
Package

125
Description

Switch Key Lock ON None ON SPDT 90° Flat Key 3A 125VAC Solder Lug 30000Cycles Panel Mount
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 7.62

Buy SK12BAW01

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SK12BAW01 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SK12BAW01 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SK12BAW01
Manufacturer	NKK
ChipWorker Part#	CW52015293
Category	Keylock Switch, Switch KeyLock
Documentation	Datasheet
Mounting Style	Panel, Solder Lug
Case/Package	125
Contact Plating	Silver
Actuator Type	Key
Voltage Rating (AC)	125 V
Current Rating	3 A
Insulation Resistance	1000 MΩ
Orientation	Vertical
Contacts Type	SPDT
Number of Positions	2 Position
Contact Resistance	10.0 mΩ
Current Rating (Max)	3A @125VAC
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-25 ℃
Voltage Rating	250 VAC
Voltage Rating (AC Max)	125 V
Maximum Contact Resistance (Max)	10 mΩ
	expand all
Size-Length	14 mm
Size-Width	14 mm
Size-Height	30 mm
Contact Material	Silver
Operating Temperature	-25℃ ~ 70℃
Housing Material	Nylon
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SK12BAW01 is a single-pole double-throw (SPDT) low and medium Security Keylock with solder lug terminals, ON-NONE-ON function, low security lock mechanisms and silver capped copper with silver plating stationary contacts. The SK series security keylock has zinc alloy with chrome plating housing and phenolic resin (thermoset) base. The 12mm diameter bushing for easy panel cut-out preparation and high density mounting. The epoxy sealed terminals prevent entry of flux and other contaminants. The detent mechanism gives crisp, positive action for accurate switch setting.
Dust-resistant interior construction protects contacts
10mR Maximum contact resistance
1000MR at 500VDC Minimum insulation resistance
30000 cycles Minimum mechanical life
10000 cycles Minimum electrical life
