SMBJ10A Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | SMBJ10A | |
| Manufacturer | Littelfuse | |
| ChipWorker Part# | CW7248969 | |
| Category | TVS Diode | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 2 Pin | |
| Case/Package | DO-214AA | |
| Voltage Rating (DC) | 10.0 V | |
| Capacitance | 1700 pF | |
| Power Rating | 600 W | |
| Breakdown Voltage | 11.7 V | |
| Number of Positions | 2 Position | |
| Forward Voltage | 5 V | |
| Power Dissipation | 600 W | |
| Clamping Voltage | 17 V | |
| Test Current | 1 mA | |
| Max Breakdown Voltage | 12.3 V | |
| Peak Pulse Power | 600 W | |
| Min Breakdown Voltage | 11.1 V | |
| Reverse Breakdown Voltage | 11.1 V | |
| Operating Temperature (Max) | 150 ℃ | |
| Operating Temperature (Min) | -65 ℃ | |
| Junction Temperature | -65℃ ~ 150℃ | |
| expand all | ||
| Size-Length | 5.59 mm | |
| Size-Width | 3.94 mm | |
| Size-Height | 2.44 mm | |
| Operating Temperature | -65℃ ~ 150℃ (TJ) | |
| Product Lifecycle Status | Active | |
| Packaging | Tape & Reel (TR) | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| REACH SVHC Compliance Edition | 2014/12/17 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- The SMBJ series surface-mount Transient Voltage Suppression Diode designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. It is ideal for the protection of I/O interfaces, VCC bus and other vulnerable circuits. It is used for surface mounted applications in order to optimize board space.
- 600W Peak pulse power capability at 10x1000µs waveform
- Built-in strain relief
- Glass passivated chip junction
- Low incremental surge resistance
- Excellent clamping capability
- 0.01% Repetition rate (duty cycle)
- <1ps from 0V to V(BR) Minimum fast response time
- <1µA above 12V Current IR
- Available in unidirectional and bidirectional
- ESD protection of data lines in accordance with IEC 61000-4-2 (IEC801-2)
- EFT protection of data lines in accordance with IEC 61000-4-4 (IEC801-4)
- -65 to 150°C Operating temperature range
