SN65HVD234D ,CAN IC, Controller Area Network - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

124 points

Part No

SN65HVD234D
Manufacturer

TI
ChipWorker Part#

CW4049600
Category

CAN IC, Controller Area Network
Package

SOIC-8
Description

3.3V CAN Transceiver with Sleep Mode 8-SOIC -40℃ to 125℃
Documentation

Datasheet
Ships from

Moscow
Наличие

37340 pcs In Stock
Estimated Price

$ 5.81

Buy SN65HVD234D

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SN65HVD234D Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SN65HVD234D Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SN65HVD234D
Manufacturer	TI
ChipWorker Part#	CW4049600
Category	CAN IC, Controller Area Network
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.00V ~ 3.60V
Supply Current	6 mA
Number of Positions	8 Position
Data Rate	1.00 Mbps
Drivers Per Package	1
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	4.9 mm
Size-Width	3.91 mm
Size-Height	1.58 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SN65HVD234D is a CAN (Controller Area Network) transceiver with ultra low current sleep mode in 8 pin SOIC package. This CAN transceiver is used in applications employing CAN serial communication physical layer in accordance with the ISO 11898-2 standard. The SN65HVD234D provides transmit and receive capability between differential CAN bus and CAN controller with signalling rates up to 1Mbps. The SN65HVD234D features cross wire protection, overvoltage protection up to ±36V, loss of ground protection, overtemperature (thermal shutdown) protection and common mode transient protection of ±100V. The device operates over a wide -7V to 12V common mode range. The SN65HVD234D enters a low current standby mode during which the driver is switched off and receiver remains active if a high logic level is applied to the RS pin. This device enters an ultra low current sleep mode in which both driver and receiver circuits are deactivated if a low logic level is applied to EN pin (pin 5).
Single 3.3V supply voltage
Bus pins fault protection exceeds ±36V
Bus pin ESD protection exceeds ±16KV HBM
GIFT/ICT compliant
High input impedance allows for 120 nodes
Adjustable driver transition times for improved emissions performance
Unpowered node does not disturb bus
Low current standby mode of typically 200µA
Operating temperature range -40°C to 125°C
LVTTL I/Os are 5V tolerant
