SN74S00N - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

SN74S00N
Manufacturer

TI
ChipWorker Part#

CW44569497
Category

Logic Control, Logic Gate IC
Package

DIP-14
Description

NAND Gate 4Element 2IN Bipolar 14Pin PDIP Tube
Documentation

Datasheet

SN74S00N Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

SN74S00N Specifications

Attribute	Attribute Value

Part Number	SN74S00N
Manufacturer	TI
ChipWorker Part#	CW44569497
Category	Logic Control, Logic Gate IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	14 Pin
Case/Package	DIP-14
Digital Logic Level	TTL
Supply Voltage (DC)	4.75V ~ 5.25V
Number of Outputs	1 Output
Output Current	16 mA
Number of Circuits	4 Circuit
Number of Positions	14 Position
Voltage Nodes	5.00 V
Quiescent Current	2.40 mA
Number of Gates	4 Gate
Output Current Drive	-50.0 µA
Output Current (Max)	20 mA
Number of Inputs	2 Input
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	4.75V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	4.75 V
	expand all
Size-Length	19.3 mm
Size-Width	6.35 mm
Size-Height	4.57 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The SN74S00N is a quad 2-input positive-NAND Gate contains four independent circuits. This device perform the Boolean function Y = (A • B)\ or Y = A\ + B\ in positive logic.
