SS441A ,Hall Effect Sensor - Honeywell

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

174 points

Part No

SS441A
Manufacturer

Honeywell
ChipWorker Part#

CW495104
Category

Hall Effect Sensor
Package

TO-92-3
Description

Board Mount Hall Effect / Magnetic Sensors 20mA Unipolar 5V/9V/ 12V/15V/18V/24V 3Pin
Documentation

Datasheet
Ships from

Moscow
Наличие

45 pcs In Stock
Estimated Price

$ 0.35

Buy SS441A

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SS441A Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SS441A Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SS441A
Manufacturer	Honeywell
ChipWorker Part#	CW495104
Category	Hall Effect Sensor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-92-3
Number of Contacts	10 Contact
Supply Voltage (DC)	24.0 V
Current Rating	7.50 mA
Output Current	20 mA
Supply Current	10 mA
Number of Positions	3 Position
Output Current (Max)	20 mA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3.8V ~ 30V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	3.8 V
	expand all
Size-Length	4.00 mm
Size-Width	3.00 mm
Size-Height	3 mm
Size-Thickness	1.50 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
HTS Code	8542390000
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SS441A is a temperature compensated digital hall effect sensor IC in 3 pin TO-92 package. This small, versatile digital hall effect device is operated by magnetic field from permanent magnet or an electromagnet. It is designed to respond to alternating north and south poles or to south pole only. Band gap regulation provides stable operation over 3.8VDC to 30VDC supply voltage range. The SS441A is capable of continuous 20mA sinking output and may be cycled as high as 50mA maximum. Its 3.8V capability allows for use in many potential low voltage applications. The digital, open collector sinking type output is easily interfaced with wide variety of electronic circuits.
Unipolar magnetics, low gauss operating characteristics
Straight leads, 14.99mm long and 1.30mm spacing
Quad hall IC design minimizes mechanical stress effects
Temperature compensated magnetics helps provide stable operation over a wide temperature range
Automated component placement and potentially reduces installation costs
Broad supply voltage capability from 3.8VDC to 30VDC for application flexibility
Digital, open collector sink output for easy interfacing with variety of common electronic circuits
Operating temperature range from -40°C to 150°C (-40°F to 302°F)
Electrostatic sensitive device (ESD), do not open or handle except at static work station.
Do not use this product as safety or emergency stop device or in any other application where failure of product could result in personal injury.
