SSM2141SZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

SSM2141SZ
Manufacturer

ADI
ChipWorker Part#

CW13393800
Category

Amplifier, Buffer IC
Package

SOIC-8
Description

SP Amp DIFF Line Receiver Amp Single ±18V 8Pin SOIC N Tube
Documentation

Datasheet

SSM2141SZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

SSM2141SZ Specifications

Attribute	Attribute Value

Part Number	SSM2141SZ
Manufacturer	ADI
ChipWorker Part#	CW13393800
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	6.00V (min)
Operating Voltage	6V ~ 18V
Supply Current	2.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	80 dB
Bandwidth	3 MHz
Slew Rate	9.50 V/μs
Input Offset Voltage	25 µV
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	3 MHz
Minimum CMRR Range	80 dB
Supply Voltage (Max)	18 V
Supply Voltage (Min)	6 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The SSM2141SZ is an integrated Differential Amplifier intended to receive balanced line inputs in audio applications requiring a high level of noise immunity and optimum common-mode rejection. The differential line receiver typically achieves 100dB of common-mode rejection (CMR), whereas implementing an op amp with four off-the-shelf precision resistors will typically achieve only 40dB of CMR-inadequate for high-performance audio. The SSM2141 achieves low distortion performance by maintaining a large slew rate of 9.5V/µs and high open-loop gain. Distortion is less than 0.002% over the full audio bandwidth. The SSM2141 complements the SSM2142 balanced line driver. Together, this device comprises a fully integrated solution for equivalent transformer balancing of audio signals without the problems of distortion and EMI fields. Additional applications for the SSM2141 include summing signals, differential preamplifiers and 600R low distortion buffer amplifiers.
High common-mode rejection ratio
Low distortion - 0.001% typical
Fast slew rate - 9.5V/ms typical
3MHz Typical wide bandwidth
