STM32F030F4P6 - ST Microelectronics
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoSTM32F030F4P6
-
ManufacturerST Microelectronics
-
ChipWorker Part#CW22296
-
CategoryMicrocontroller, MCU IC
-
PackageTSSOP-20
-
DescriptionMCU 32Bit ARM Cortex M0 RISC 16KB Flash 2.5V/3.3V 20Pin TSSOP Tube
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
STM32F030F4P6 Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
STM32F030F4P6 Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | STM32F030F4P6 |
| Manufacturer | ST Microelectronics |
| ChipWorker Part# | CW22296 |
| Category | Microcontroller, MCU IC |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | TSSOP-20 |
| Frequency | 48 MHz |
| Operating Voltage | 2.4V ~ 3.6V |
| Number of Positions | 20 Position |
| Clock Speed | 48 MHz |
| RAM Memory Size | 4 KB |
| Number of Bits | 32 Bit |
| FLASH Memory Size | 16 KB |
| Number of ADCs | 1 ADC |
| Number of Inputs and Outputs | 15 Input IO |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 2.4V ~ 3.6V |
| Supply Voltage (Max) | 3.6 V |
| Supply Voltage (Min) | 2.4 V |
| expand all | |
| Size-Length | 6.6 mm |
| Size-Width | 4.5 mm |
| Size-Height | 1.05 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2014/06/16 |
| ECCN Code | 3A991A2 |
Product Description
- The STM32F030F4P6 is a Microcontroller Unit incorporates the high-performance ARM Cortex -M0 32-bit RISC core operating at a 48MHz frequency, high-speed embedded memories and an extensive range of enhanced peripherals and I/Os. All devices offer standard communication interfaces, one 12-bit ADC, seven general-purpose 16-bit timers and an advanced-control PWM timer.
- CRC calculation unit
- 4 to 32MHz Crystal oscillator
- 32kHz Oscillator for RTC with calibration
- Internal 8MHz RC with x6 PLL option
- Internal 40kHz RC oscillator
- 0 to 3.6V Conversion range
- 2.4 to 3.6V Separate analogue supply
- Independent and system watchdog timers
- SysTick timer
- Communication interfaces
- Serial wire debug (SWD)
