STM32F103RCY6TR ,Microcontroller, MCU IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

136 points

Part No

STM32F103RCY6TR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW6964255
Category

Microcontroller, MCU IC
Package

WLCSP-64
Description

MCU 32Bit ARM Cortex M3 RISC 256KB Flash 2.5V/3.3V 64Pin WLCSP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 3.4

Buy STM32F103RCY6TR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STM32F103RCY6TR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STM32F103RCY6TR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STM32F103RCY6TR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW6964255
Category	Microcontroller, MCU IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	64 Pin
Case/Package	WLCSP-64
Frequency	72 MHz
Supply Voltage (DC)	2.00V (min)
Number of Positions	64 Position
Clock Speed	72.0 MHz
RAM Memory Size	48 KB
Number of Bits	32 Bit
FLASH Memory Size	256 KB
Number of ADCs	3 ADC
Number of Inputs and Outputs	51 Input IO
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	400 mW
Number of DACs	2 DAC
Supply Voltage	2V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2 V
	expand all
Size-Length	10.2 mm
Size-Width	10.2 mm
Size-Height	1.45 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A991A2

Similar & Replacement Parts

Similar products

Product Description

The STM32F103RCY6TR is a high density performance line STM32 F1 series 32-bit Microcontroller incorporates the high-performance ARM Cortex-M3 RISC core operating at a 72MHz frequency, high speed embedded memories (Flash memory up to 256kB and SRAM up to 48KB) and an extensive range of enhanced peripherals and I/Os connected to two APB buses. This device offer three 12-bit ADCs, four general purpose 16-bit timers plus one PWM timer, as well as standard communication interfaces - up to two I²Cs, three SPIs, two I²Ss, one SDIO, five USARTs, an USB and a CAN.
72MHz Maximum frequency, 1.25 DMIPS/MHz (Dhrystone 2.1) performance
Single cycle multiplication and hardware division
Flexible static memory controller with 4 chip select
LCD parallel interface, 8080/6800 modes
Clock, reset and supply management
POR, PDR and programmable voltage detector (PVD)
4 to 16MHz Crystal oscillator
Internal 8MHz factory trimmed RC
Internal 40kHz RC
32kHz Oscillator for RTC with calibration
Sleep, stop and standby modes
VBAT supply for RTC and backup registers
12-channel DMA Controller
Serial wire debug (SWD) and JTAG interfaces
Cortex-M3 embedded trace macrocell™
2 x Watchdog timers (Independent and window)
SysTick Timer
CAN interface (2.0B Active)
USB 2.0 full speed interface
96-bit Unique ID
