Part No

STP75NS04Z
Manufacturer

ST Microelectronics
ChipWorker Part#

CW11116703
Category

MOSFET, MOSFET Transistor
Package

TO-220-3
Description

TO-220 N-CH 33V 80A
Documentation

Datasheet

STP75NS04Z Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STP75NS04Z Specifications

Attribute	Attribute Value

Part Number	STP75NS04Z
Manufacturer	ST Microelectronics
ChipWorker Part#	CW11116703
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Channels	1 Channel
Drain to Source Resistance (on) (Rds)	11 mΩ
Polarity	N-CH
Power Dissipation	110 W
Drain to Source Voltage (Vds)	33 V
Breakdown Voltage (Drain to Source)	33 V
Continuous Drain Current (Ids)	80A
Rise Time	248 ns
Input Capacitance (Ciss)	1860pF @25V(Vds)
Input Power (Max)	110 W
Fall Time	85 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	110W (Tc)
	expand all
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	15.75 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Description
This fully clamped MOSFET is produced by using the latest advanced Company’s Mesh Overlay process which is based on a novel strip layout. The inherent benefits of a new technology coupled with the extra clamping capabilities make this product particularly suitable for the harshest operation conditions such as those encoured in power tools. Any other application requiring extra ruggedness is also recommended.
■ Low capacitance and gate charge
■ 100% avalanche tested
■ 175°C maximum junction temperature
Applications
■ Switching application
■ Power tools
