TC54VN3002ECB713 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TC54VN3002ECB713
Manufacturer

Microchip
ChipWorker Part#

CW13111817
Category

Power Monitor
Package

SOT-23-3
Description

Processor Supervisor 3V 7V to 10V 1 Open Drain 3Pin SOT-23A T/R
Documentation

Datasheet

TC54VN3002ECB713 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TC54VN3002ECB713 Specifications

Attribute	Attribute Value

Part Number	TC54VN3002ECB713
Manufacturer	Microchip
ChipWorker Part#	CW13111817
Category	Power Monitor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Supply Voltage (DC)	700mV (min)
Operating Voltage	0.7V ~ 10V
Supply Current	1.00 µA
Power Dissipation	240 mW
Quiescent Current	1.10 µA
Threshold Voltage	3 V
Reset Threshold Voltage (Min)	2.94 V
Reset Threshold Voltage (Max)	3.06 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	240 mW
Supply Voltage	10 V
Supply Voltage (Max)	6 V
	expand all
Size-Length	3.1 mm
Size-Width	1.8 mm
Size-Height	1.3 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The TC54VN3002ECB713 is a Voltage Detector with N-channel open-drain output. It is suitable for battery-powered applications because of their extremely low 1µA operating current. Each part is laser-trimmed to the desired threshold voltage, which can be specified from 1.4 to 6V with a 2% tolerance. During operation, the output (VOUT) remains in the logic-high state as long as VIN is greater than the specified threshold voltage (VDET-). When VIN falls below VDET-, the output is driven to a logic-low. VOUT remains low until VIN rises above VDET- by an amount VHYST, when it resets to a logic high state.
