TIL199 - ISOCOM Components

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TIL199
Manufacturer

ISOCOM Components
ChipWorker Part#

CW42489169
Category

Optocoupler, Optoisolator
Package

DIP
Description

ISOCOM TIL199 Optocoupler, Darlington Output, 4Channel, DIP, 16Pins, 50mA, 5.3kV, 500%
Documentation

Datasheet

TIL199 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TIL199 Specifications

Attribute	Attribute Value

Part Number	TIL199
Manufacturer	ISOCOM Components
ChipWorker Part#	CW42489169
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP
Output Voltage	35 V
Number of Channels	4 Channel
Number of Positions	16 Position
Forward Voltage	1.4 V
Input Current	20 mA
Power Dissipation	0.2 W
Rise Time	100 µs
Isolation Voltage	5.3 kV
Forward Current	50 mA
Reverse Breakdown Voltage	5 V
Maximum Forward Voltage (Max)	1.4 V
Forward Current (Max)	50 mA
Fall Time	100 µs
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	200 mW
	expand all
Operating Temperature	-55℃ ~ 100℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The TIL199 is a 4-channel high density phototransistor Optically Coupled Isolator consists of an infrared LED and a NPN silicon photo transistor. It is tested for a CTR of 500% minimum.
