The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TLE7368E
Manufacturer

Infineon
ChipWorker Part#

CW18267438
Category

DC to DC Converter
Package

PG-DSO-36
Description

**DC-DC 42V 2.5A D SO-36 SMD **
Documentation

Datasheet

TLE7368E Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TLE7368E Specifications

Attribute	Attribute Value

Part Number	TLE7368E
Manufacturer	Infineon
ChipWorker Part#	CW18267438
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	36 Pin
Case/Package	PG-DSO-36
Number of Outputs	3 Output
Output Current	30 mA
Number of Positions	36 Position
Switching Frequency	425 kHz
Input Voltage (Max)	45 V
Input Voltage (Min)	4.5 V
Output Voltage (Max)	5.1 V
Output Voltage (Min)	4.9 V
Output Current (Max)	700mA, 800mA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Min)	4.5 V
Input Voltage	4.5V ~ 45V
	expand all
Size-Length	12.8 mm
Size-Width	11 mm
Size-Height	2.55 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The TLE7368E is a multifunctional Power Supply Circuit especially designed for automotive powertrain systems using a standard 12V battery. The regulator follows the concept of its predecessor TLE6368, where the output of a pre-regulator feeds the inputs of the micro"s linear supplies. In detail, the TLE7368 cascades a buck converter with linear regulators and voltage followers to achieve lowest power dissipation. This configuration allows to power the application even at high ambient temperatures. The step-down converter delivers a pre-regulated voltage of 5.5V with a minimum peak current capability of 2.5A. Supplied by this step down converter two low drop linear post-regulators offer 5 and 3.3V (2.6V) with high accuracy. The current capability of the regulators is 800 and 700mA. The 3.3V (2.6V) linear regulator does have its own input allowing to insert a dropper from the Buck output to reduce the on chip power dissipation if necessary.
Hardware controlled on/off logic
Window watchdog circuit
Overcurrent protection on all regulators
Power sequencing on controller supplies
Overtemperature shutdown
High efficiency for complex supply systems
High buck current maintains operation under short-circuit condition
Low current consumption in stand-by
Easy realization of multiple supply rail systems
Monitoring and control of µC by reset generator and window-watchdog
Stand-by regulator with lowest current consumption
