TNY264GN ,AC to DC Converter, AC/DC Power Module - Power Integrations

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

121 points

Part No

TNY264GN
Manufacturer

Power Integrations
ChipWorker Part#

CW2503275
Category

AC to DC Converter, AC/DC Power Module
Package

SMD-8
Description

AC-DC Off-Line Switcher, Integrated Power MOSFET, 85-265VAC input, 132kHz, SOIC-8
Documentation

Datasheet
Ships from

Moscow
Наличие

16 pcs In Stock
Estimated Price

$ 3.37

Buy TNY264GN

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TNY264GN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TNY264GN Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TNY264GN
Manufacturer	Power Integrations
ChipWorker Part#	CW2503275
Category	AC to DC Converter, AC/DC Power Module
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SMD-8
Frequency	132 kHz
Supply Voltage (DC)	374V (max)
Power Rating	9 W
Number of Outputs	1 Output
Output Voltage	700 V
Output Current	400 mA
Breakdown Voltage	700 V
Supply Current	225 µA
Number of Positions	8 Position
Output Power	6 W
Switching Frequency	132 kHz
Duty Cycle	65 %
Input Voltage (AC Max)	265 v
Input Voltage (AC Min)	85 v
Maximum Duty Cycle	68 %
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	85.265 V
	expand all
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

TEXTOOL 208-7391-55-1902

Product Description

The TNY264GN is a TinySwitch-II, EcoSmart, enhanced energy efficient low power off line switcher in 8 pin SMD package. This device integrates 700V power MOSFET, oscillator, high voltage switched current source, current limit and thermal shutdown circuitry onto a monolithic device. The start up and operating power are derived directly from voltage on DRAIN pin by eliminating need for bias winding and associated circuitry. In addition, the TinySwitch-II device incorporates auto restart, line undervoltage sense and frequency jittering. An innovative design minimizes audio frequency components in simple ON/OFF control scheme to practically eliminate audible noise with standard taped/varnished transformer construction. The fully integrated auto restart circuit safely limits output power during fault conditions such as output short circuit or open loop. The TNY264GN meets CEC, Energy Star and EU requirements.
Output power of 9W at 230VAC and 6W at 85VAC to 265VAC in open frame design
Output power of 5.5W at 230VAC and 4W at 85VAC to 265VAC in non ventilated enclosed adapter
Maximum duty cycle of 65%
Built-in circuitry practically eliminates audible noise with ordinary dip varnished transformer
132KHz operation reduces transformer size, uses EF12.6 or EE13 cores for low cost and small size
Very tight tolerances and negligible temperature variation eases design and low cost
Cost effective replacement for bulky regulated liners
Simple design practically eliminates rework in manufacturing
Built-in current limit and thermal protection improves safety
Operating junction temperature from -40°C to 150°C
