TPS73630DBVT - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TPS73630DBVT
Manufacturer

TI
ChipWorker Part#

CW13403604
Category

Voltage Regulator
Package

SOT-23-5
Description

Single Channel LDO Single Output LDO, 400mA, Fixed(3V), Cap free, Low Noise, Reverse Current Protection LDO Regulator Pos 3V 0.4A 5Pin SOT-23 T/R
Documentation

Datasheet

TPS73630DBVT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TPS73630DBVT Specifications

Attribute	Attribute Value

Part Number	TPS73630DBVT
Manufacturer	TI
ChipWorker Part#	CW13403604
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-23-5
Number of Outputs	1 Output
Input Voltage (DC)	5.50V (max)
Output Voltage	3 V
Output Current	400 mA
Supply Current	550µA ~ 1mA
Number of Positions	5 Position
Power Dissipation	560 W
Quiescent Current	400 µA
Output Capacitor Type	Ceramic
voltage rating	75 mV
Number of Regulated Outputs	1 Output
Input Voltage (Max)	5.5 V
Input Voltage (Min)	1.7 V
Output Voltage (Min)	3 V
Output Current (Max)	400 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	1 %
Input Voltage	≤5.5 V
	expand all
Size-Length	2.9 mm
Size-Width	1.6 mm
Size-Height	1.15 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

The TPS73630DBVT is a 3V fixed output low-dropout (LDO) Linear Regulator uses a new topology - an NMOS pass element in a voltage-follower configuration. This topology is stable using output capacitors with low ESR and even allows operation without a capacitor. It also provides high reverse blockage (low reverse current) and ground pin current that is nearly constant over all values of output current. The device uses an advanced BiCMOS process to yield high precision while delivering very low-dropout (LDO) voltages and low ground pin current. Current consumption, when not enabled, is under 1µA and ideal for portable applications. The extremely low output noise is ideal for powering VCOs. This device is protected by thermal shutdown and foldback current limit.
Stable with no output capacitor or any value or type of capacitor
75mV Ultra-low dropout voltage
Excellent load transient response - with or without optional output capacitor
New NMOS topology delivers low reverse leakage current
30µVRMS Low noise (10Hz to 100kHz)
0.5% Initial accuracy
1% Overall accuracy over line, load and temperature
<1µA Quiescent current (IQ) in shutdown mode
Thermal shutdown and specified minimum and maximum current limit protection
Green product and no Sb/Br
