UC3844N ,PWM Controller IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

208 points

Part No

UC3844N
Manufacturer

TI
ChipWorker Part#

CW5683084
Category

PWM Controller IC
Package

DIP-8
Description

Driver; PWM controller; 1A; 1W; Channels:1; 16÷30V; 500kHz; DIP8
Documentation

Datasheet
Ships from

Moscow
Наличие

2430 pcs In Stock
Estimated Price

$ 1.26

Buy UC3844N

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

UC3844N Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

UC3844N Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	UC3844N
Manufacturer	TI
ChipWorker Part#	CW5683084
Category	PWM Controller IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Frequency	450 kHz
Supply Voltage (DC)	25.0V (max)
Operating Voltage	16V ~ 30V
Power Rating	1 W
Number of Outputs	1 Output
Input Voltage (DC)	25.0 V
Output Voltage	13.5 V
Output Current	1 A
Supply Current	25 mA
Number of Channels	1 Channel
Number of Positions	8 Position
Input Current	11.0 mA
Power Dissipation	1000 mW
Quiescent Current	11.0 mA
Number of Regulated Outputs	1 Output
Rise Time	50 ns
Switching Frequency	500kHz (MAX)
Topology	Buck, Boost, Flyback, Forward
Duty Cycle	50 %
Maximum Duty Cycle	50 %
Fall Time	50 ns
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	1000 mW
Supply Voltage	10V ~ 30V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	10 V
Input Voltage	25 V
	expand all
Size-Length	9.81 mm
Size-Width	6.35 mm
Size-Height	4.57 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The UC3844N is a Current Mode PWM Controller optimized for off-line and DC to DC converters. This device provides the necessary features to implement off-line or DC-to-DC fixed frequency current mode control schemes with a minimal external parts count. Internally implemented circuits include under-voltage lockout featuring start up current less than 1mA, a precision reference trimmed for accuracy at the error amp input, logic to insure latched operation, a PWM comparator which also provides current limit control and a totem pole output stage designed to source or sink high peak current. The output stage, suitable for driving N-channel MOSFETs, is low in the off state.
Optimized for off-line and DC to DC converters
Low start up current (<1mA)
Automatic feed forward compensation
Pulse-by-pulse current limiting
Enhanced load response characteristics
Under-voltage lockout with hysteresis
Double pulse suppression
High current totem pole output
Internally trimmed bandgap reference
Green product and no Sb/Br
