UCC3895DW ,Power Management IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

259 points

Part No

UCC3895DW
Manufacturer

TI
ChipWorker Part#

CW1382767
Category

Power Management IC
Package

SOIC-20
Description

Soft Sw PWM Cntrlr 4Out BICMOS PH SHIFT RES 1MHz 20Pin SOIC Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

10 pcs In Stock
Estimated Price

$ 5.14

Buy UCC3895DW

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

UCC3895DW Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

UCC3895DW Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	UCC3895DW
Manufacturer	TI
ChipWorker Part#	CW1382767
Category	Power Management IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC-20
Frequency	500 kHz
Supply Voltage (DC)	10.0V (min)
Power Rating	650 mW
Number of Outputs	1 Output
Input Voltage (DC)	12.0 V
Output Voltage	250 mV
Output Current	10 mA
Supply Current	5.00 mA
Number of Channels	4 Channel
Number of Positions	20 Position
Power Dissipation	650 mW
Number of Regulated Outputs	4 Output
Rise Time	20 ns
Switching Frequency	1 MHz
Topology	Buck
Duty Cycle	100 %
Output Voltage (Max)	16.8 V
Maximum Duty Cycle	100 %
Fall Time	20 ns
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	650 mW
Supply Voltage	10V ~ 16.5V
Supply Voltage (Max)	16.5 V
Supply Voltage (Min)	10 V
Input Voltage	12 V
	expand all
Size-Length	12.8 mm
Size-Width	7.52 mm
Size-Height	2.35 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
ECCN Code	EAR99
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

The UCC3895DW is a BiCMOS Advanced Phase Shift PWM Controller that implements control of a full-bridge power stage by phase shifting the switching of one half-bridge with respect to the other. The device allows constant frequency pulse-width modulation in conjunction with resonant zero-voltage switching to provide high efficiency at high frequencies. The part is used either as a voltage-mode or current-mode controller. It improves on that controller family with additional features such as enhanced control logic, adaptive delay set and shutdown capability. Because the device is built using the BCDMOS process, it operates with dramatically less supply current than its bipolar counterparts. The UCC3895 operates with a maximum clock frequency of 1MHz.
