UCS1002-1-BP-TR ,USB Controller IC - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

98 points

Part No

UCS1002-1-BP-TR
Manufacturer

Microchip
ChipWorker Part#

CW26039932
Category

USB Controller IC
Package

QFN-20
Description

MICROCHIP UCS1002-1-BP-TR USB Interface, Power Controller, USB 2.0, 4.5V, 5.5V, QFN, 20Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

178024 pcs In Stock
Estimated Price

$ 0.66

Buy UCS1002-1-BP-TR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

UCS1002-1-BP-TR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

UCS1002-1-BP-TR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	UCS1002-1-BP-TR
Manufacturer	Microchip
ChipWorker Part#	CW26039932
Category	USB Controller IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	QFN-20
Supply Voltage (DC)	4.50V (min)
Supply Current	650 µA
Number of Positions	20 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.9V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
Input Voltage	4.5V ~ 5.5V
	expand all
Size-Length	4.1 mm
Size-Width	4.1 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A991.a.2

Similar & Replacement Parts

Similar products

Product Description

The UCS1002-1-BP-TR is a Programmable USB Port Power Controller with charger emulation. It provides an USB port power switch for precise control of up to 2.5 amperes continuous current with over-current limit (OCL), dynamic thermal management, latch or auto-recovery (low test current) fault handling, selectable active low or high enable, under- and over-voltage lockout, back-drive protection and back-voltage protection. Split supply support for VS and VDD is an option for low power in system standby states. This gives battery operated applications, like notebook PCs, the ability to detect attachments from a sleep or off state. After the attach detection is flagged, the system can decide to wake up and/or provide charging. In addition to power switching and current limiting modes, the UCS1002 will automatically charge a wide variety of portable devices, including USB-IF BC1.2, YD/T-1591 (2009), most Apple® and RIM® and many others.
Port power switch with two current limits
Selectable/automatic cycling of USB data line charger emulation profiles
Self-contained current monitoring and charge rationing for power allocation applications
Automatic shutdown when battery full option
Low power attach detection and open-drain A_DET# pin
Ultra low power sleep state
Optional split supply support for VBUS and VDD for low power in system standby states
Wake on attach USB
SMBus 2.0 /I²C Communications

expand all
