VLHW4100 - VISHAY

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

VLHW4100
Manufacturer

VISHAY
ChipWorker Part#

CW5203604
Category

Based LED
Package

T-1
Description

LED, Ultrabright, White, Through Hole, T-1 (3mm), 20mA, 3.2V, 7.15cd
Documentation

Datasheet

VLHW4100 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

VLHW4100 Specifications

Attribute	Attribute Value

Part Number	VLHW4100
Manufacturer	VISHAY
ChipWorker Part#	CW5203604
Category	Based LED
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	T-1
Number of Positions	2 Position
Forward Voltage	3.2 V
Luminous Intensity	7.15 cd
Viewing Angle	45°
Power Dissipation	95 W
Test Current	20 mA
Forward Current	20 mA
Forward Current (Max)	25 mA
Power Dissipation (Max)	95 mW
	expand all
Size-Height	4.30 mm
Color	White
Operating Temperature	-40℃ ~ 95℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The VLHW4100 from Vishay is VLHW41 series ultrabright white LED. This is a clear, untinted 3mm LED for high end applications where supreme luminous intensity is required. This lamp utilizes the highly developed ultrabright InGaN technologies. The lens and the viewing angle is optimized to achieve best performance of light output and visibility. It is used in Interior and exterior lighting, outdoor LED panels, instrumentation and front panel indicators, replaces incandescent lamps and light guide compatible.
InGaN and converter technology
White colour LED
Luminous intensity of 7150 (typ) at IF = 20mA
Maximum forward voltage of 3.8V at IF = 20mA
Angle of half intensity of ±22.5°
Power dissipation of 95mW
ESD withstand voltage up to 2KV according to JESD22-A114-B
