1N4742A ,Zener Diode, Zener - Taiwan Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

45 points

Part No

1N4742A
Manufacturer

Taiwan Semiconductor
ChipWorker Part#

CW66937437
Category

Zener Diode, Zener
Package

DO-41
Description

TAIWAN SEMICONDUCTOR 1N4742A Zener Single Diode, 12V, 1W, DO-41, 5%, 2Pins, 150℃
Documentation

Datasheet
Ships from

Moscow
Наличие

22247 pcs In Stock
Estimated Price

$ 0.27

Buy 1N4742A

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

1N4742A Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

1N4742A Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	1N4742A
Manufacturer	Taiwan Semiconductor
ChipWorker Part#	CW66937437
Category	Zener Diode, Zener
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	DO-41
Number of Positions	2 Position
Power Dissipation	1 W
Test Current	21 mA
Zener Voltage	12 V
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	1000 mW
	expand all
Size-Length	5.2 mm
Size-Width	2.7 mm
Size-Height	2.7 mm
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The 1N4742A from Multicomp is an axial leaded zener diode which provides a stable reference voltage in DO-41 package. This device features high reliability, very sharp reverse characteristic and low reverse current level. This are special type of semiconductor diode that also allows current to flow in the opposite direction but only when exposed to enough voltage.
Maximum power dissipation of 1W
Operating junction temperature of 200°C
Zener voltage Vz of 12V
Forward voltage VF of 1.2V at IF 200mA
