A000053 - Arduino

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

A000053
Manufacturer

Arduino
ChipWorker Part#

CW3029203
Category

Microprocessor Primary Platform
Description

ATmega32u4 Microcontroller Micro Development Board 16MHz CPU 2.5KB RAM 1KB/32KB EEPROM/Flash
Documentation

Datasheet

A000053 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

A000053 Specifications

Attribute	Attribute Value

Part Number	A000053
Manufacturer	Arduino
ChipWorker Part#	CW3029203
Category	Microprocessor Primary Platform
Documentation	Datasheet
RAM Memory Size	2.5 KB
Number of Bits	8 Bit
Core Architecture	AVR
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Product Description

The A000053 is a Arduino Micro development board based on the ATmega32u4 microcontroller. The ATmega32u4 is a 8bit AVR RISC based microcontroller featuring 32KB flash memory, 2.5KB SRAM, 1KB EEPROM, USB 2.0 full speed/low speed device, 10bit A to D converter and JTAG interface for on chip debug. The board contains everything needed to support the microcontroller, simply connect it to a computer with a micro USB cable to get started. It has a form factor that enables it to be easily placed on a breadboard. The Micro is similar to the Arduino Leonardo in that the ATmega32u4 has built in USB communication, eliminating the need for a secondary processor. This allows the Micro to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial/COM port. It also has other implications for the behaviour of the board. The Arduino Micro can be powered via the micro USB connection or with an external power supply. The power source is selected automatically.
16MHz crystal oscillator
ICSP header
Reset button
Micro USB connection
20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs)
Input voltage (recommended) range from 7V to 12V
Input Voltage (limit) range from 6V to 20V
32KB flash memory of which 4KB used by bootloader
2.5KB SRAM
1KB EEPROM
The recommended range is 7 to 12 volts, if using more than 12V the voltage regulator may overheat and damage the board.
