AD5262 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD5262
Manufacturer

ADI
ChipWorker Part#

CW543109903
Description

+15V or 5V, Dual-Channel, SPI Compatible, 256Position Digital Potentiometer
Documentation

Datasheet

AD5262 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD5262 Specifications

Attribute	Attribute Value

Part Number	AD5262
Manufacturer	ADI
ChipWorker Part#	CW543109903
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active

Product Description

Product Details
The AD5260 and AD5262 are 1- and 2-channel, 256 position, SPI interface digitally controlled, variable resistor (VR) devices. These parts operate from either a single +5 V to +15 V supply or a dual ±5 V supply, extending terminal voltage adjustment to these supply voltages. (Most industry digital potentiometers are limited to a 5 V operating range). These devices perform the same electronic adjustment function as a potentiometer or variable resistor while offering solid-state reliability and electronic packaging compactness. These devices are offered in the thin 1.1 mm height TSSOP 14- and 16-lead surface mount packages.
### Features and Benefits
AD5262 – 2-Channel (Independently Programmable)
5 V to 15 V Single-Supply; ±5.5 V Dual-Supply Operation
Potentiometer Replacement 20 kΩ, 50 kΩ, 200 kΩ
256 Positions
AD5260 – 1-Channel
Low Temperature Coefficient
35 ppm/°C
4-Wire SPI-Compatible Serial Data Input
Power ON Mid-Scale Prese
