Product Description

Product Details
The AD622 is a low cost, moderately accurate instrumentation amplifier in the traditional pin configuration that requires only one external resistor to set any gain between 2 and 1000. For a gain of 1, no external resistor is required. The AD622 is a complete difference or subtractor amplifier system that also provides superior linearity and common-mode rejection by incorporating precision laser-trimmed resistors.
The AD622 replaces low cost, discrete, two or three op amp instrumentation amplifier designs and offers good common-mode rejection, superior linearity, temperature stability, reliability, power, and board area consumption. The low cost of the AD622 eliminates the need to design discrete instrumentation amplifiers to meet stringent cost targets. While providing a lower cost solution, it also provides performance and space improvements.
**Applications**
Transducer interface
Low cost thermocouple amplifier
Industrial process controls
Difference amplifier
Low cost data acquisition
### Features and Benefits
Easy to use
Low cost solution
Higher performance than two or three op amp design
Unity gain with no external resistor
Optional gains with one external resistor
(Gain range: 2 to 1000)
Wide power supply range: ±2.6 V to ±15 V
Available in 8-lead PDIP and 8-lead SOIC_N packages
Low power, 1.5 mA maximum supply current
DC performance
0.15% gain accuracy: G = 1
125 μV maximum input offset voltage
1.0 μV/°C maximum input offset drift
5 nA maximum input bias current
66 dB minimum common-mode rejection ratio: G = 1
Noise
12 nV/√Hz @ 1 kHz input voltage noise
0.60 μV p-p noise: 0.1 Hz to 10 Hz, G = 10
AC characteristics
800 kHz bandwidth: G = 10
10 μs settling time to 0.1% @ G = 1 to 100
1.2 V/μs slew rate
