AD8397ARZ ,Operational Amplifier, OP Amp IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

223 points

Part No

AD8397ARZ
Manufacturer

ADI
ChipWorker Part#

CW545008
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

ANALOG DEVICES AD8397ARZ Operational Amplifier, Dual, 2 Amplifier, 69MHz, 53V/µs, 3V to 24V, SOIC, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

31 pcs In Stock
Estimated Price

$ 12.08

Buy AD8397ARZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD8397ARZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD8397ARZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD8397ARZ
Manufacturer	ADI
ChipWorker Part#	CW545008
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	24.0 V
Output Current	230mA @5V
Supply Current	11 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	76 dB
Input Capacitance	1.40 pF
Bandwidth	69 MHz
Slew Rate	53.0 V/μs
Gain Bandwidth Product	35 MHz
Input Impedance	87.0 kΩ
Input Offset Voltage	1 mV
Input Bias Current	200 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	69 MHz
Minimum CMRR Range	76 dB
Supply Voltage	3V ~ 24V
Supply Voltage (Max)	24 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The AD8397ARZ is a Rail-to-rail High Output Current Amplifier capable of driving heavy loads with excellent linearity. The common-emitter rail-to-rail output stage surpasses the output voltage capability of typical emitter-follower output stages and can swing to within 0.5V of either rail while driving a 25R load. The low distortion, high output current and wide output dynamic range makes the amplifier ideal for applications that require a large signal swing into a heavy load. Fabricated with high speed extra fast complementary bipolar high voltage (XFCB-HV) process, the high bandwidth and fast slew rate of the AD8397 keep distortion to a minimum.
Dual operational amplifier
