Part No

ADC08200CIMT
Manufacturer

TI
ChipWorker Part#

CW61698663
Category

Analog to Digital, ADC IC
Package

TSSOP-24
Description

8Bit, 200MSPS Analog-to-Digital Converter (ADC) 24-TSSOP -40℃ to 85℃
Documentation

Datasheet
Ships from

Moscow
Наличие

132782 pcs In Stock
Estimated Price

$ 0.17

Buy ADC08200CIMT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADC08200CIMT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADC08200CIMT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADC08200CIMT
Manufacturer	TI
ChipWorker Part#	CW61698663
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	TSSOP-24
Supply Voltage (DC)	2.40V (min)
Supply Current	70.0 mA
Number of Channels	1 Channel
Number of Positions	24 Position
Number of Bits	8 Bit
Power Dissipation	21 W
Sample Rate	200 Msps
Power Consumption	210 mW
Number of ADCs	1 ADC
Number of Inputs	1 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	21 mW
Number of Input Channels	1 Channel
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2.4 V
Input Voltage	1.6 V
	expand all
Size-Length	7.8 mm
Size-Width	4.4 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The ADC08200CIMT is a CMOS 8-bit Analogue-to-digital Converter with an on-chip track-and-hold circuit. Optimized for low power, small size and ease of use, this product operates at conversion rates up to 200MSPS while consuming just 210mW per MHz of clock frequency. Raising the PD pin puts the ADC into a Power Down mode where it consumes about 1mW. The unique architecture achieves 7.3 Effective Bits with 50MHz input frequency. The ADC is resistant to latch-up and the outputs are short-circuit proof. The top and bottom of the ADC"s reference ladder are available for connections, enabling a wide range of input possibilities. The digital outputs are TTL/CMOS compatible with a separate output power supply pin to support interfacing with 3V or 2.5V logic. The digital inputs (CLK and PD) are TTL/CMOS compatible. The output data format is straight binary.
