ADC3443IRTQ25 ,Analog to Digital, ADC IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

52 points

Part No

ADC3443IRTQ25
Manufacturer

TI
ChipWorker Part#

CW122129266
Category

Analog to Digital, ADC IC
Package

VQFN-56
Description

TEXAS INSTRUMENTS ADC3443IRTQ25 Analog to Digital Converter, 4CH, 14Bit, 80MSPS, Single, 1.7V, 1.9V, VQFN
Documentation

Datasheet
Ships from

Moscow
Наличие

23 pcs In Stock
Estimated Price

$ 79.56

Buy ADC3443IRTQ25

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADC3443IRTQ25 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADC3443IRTQ25 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADC3443IRTQ25
Manufacturer	TI
ChipWorker Part#	CW122129266
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Number of Pins	56 Pin
Case/Package	VQFN-56
Supply Voltage (DC)	1.70V (min)
Number of Channels	4 Channel
Number of Positions	56 Position
Number of Bits	14 Bit
Power Dissipation	288 mW
Sample Rate	80 Msps
Power Consumption	288 mW
Number of ADCs	4 ADC
Number of Inputs	4 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	350 mW
Number of Input Channels	4 Channel
Supply Voltage (Max)	1.9 V
Supply Voltage (Min)	1.7 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The ADC3443IRTQ25 is a quad-channel, 14bit analogue to digital converter in 56 pin VQFN package. The device is designed specifically to support demanding, high input frequency signals with large dynamic range requirements. An input clock divider allows more flexibility for system clock architecture design while the SYSREF input enables complete system synchronization. It supports serial LVDS interface in order to reduce the number of interface lines, thus allowing for high system integration density. The serial LVDS interface is two-wire, where each ADC data are serialized and output over two LVDS pairs. An internal phase locked loop (PLL) multiplies the incoming ADC sampling clock to derive the bit clock that is used to serialize the 14bit output data from each channel. In addition to the serial data streams, the frame and bit clocks are also transmitted as LVDS outputs. It is used in multi-carrier, multi-mode cellular base stations, munitions guidance, radar and smart antenna arrays.
Supply voltage range from 1.7V to 1.9V
Operating temperature range from -40°C to 85°C
Maximum ADC clock frequency of 80MSPS
SNR = 72.4dBFS, SFDR = 87dBc at fIN = 70MHz
Maximum analogue and digital supply current is 125mA and 101mA
Maximum total power dissipation of 350mW
Maximum global power down dissipation is 17mW
Standby power down dissipation is 103mW
ESD sensitive device, take proper precaution while handling the device.
