APL1117 - Anpec

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

APL1117
Manufacturer

Anpec
ChipWorker Part#

CW194104740
Package

SOT-223
Description

1A Low Dropout Fast Response Positive Adjustable Regulator and Fixed 1.2V,1.8V, 2.5V, 2.85V, 3.3V and 5V
Documentation

Datasheet

APL1117 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

APL1117 Specifications

Attribute	Attribute Value

Part Number	APL1117
Manufacturer	Anpec
ChipWorker Part#	CW194104740
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	SOT-223
	expand all
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

General Description
The APL1117 is a low dropout three-terminal adjustable regulators with 1A output current capability. In order to obtain lower dropout voltage and faster transient response, which is critical for low voltage applications,the APL1117 has been optimized. The device is available in an adjustable version and fixed output voltages of 1.2V ,1.8V , 2.5V , 2.85V , 3.3V , and 5V.
Features
· Guaranteed Output V oltage Accuracy within 2%
· Fast Transient Response
· Guaranteed Dropout Voltage at Multiple Currents
· Load Regulation : 0.1% Typ.
· Line Regulation : 0.03% Typ.
· Low Dropout Voltage : 1.1V Typ. at IOUT=1A
· Current-Limit : 1A T yp. at TJ=25°C
· On-Chip Thermal Limiting : 150°C Typ.
· Adjustable Output : 1.25~10.7V
· Standard 3-pin TO-220, TO-252-3, TO-263-3 and SOT-223 Power Packages
· Lead Free and Green Devices Available
(RoHS Compliant)
