CA3420EZ ,Operational Amplifier, OP Amp IC - Intersil

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

79 points

Part No

CA3420EZ
Manufacturer

Intersil
ChipWorker Part#

CW77549138
Category

Operational Amplifier, OP Amp IC
Package

DIP-8
Description

INTERSIL CA3420EZ Operational Amplifier, Single, 1 Amplifier, 500kHz, 0.5V/µs, 2V to 20V, DIP, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 2.49

Buy CA3420EZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

CA3420EZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

CA3420EZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	CA3420EZ
Manufacturer	Intersil
ChipWorker Part#	CW77549138
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	22.0 V
Supply Current	450 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Bandwidth	500 kHz
Slew Rate	500 mV/μs
Gain Bandwidth Product	500 kHz
Input Offset Voltage	5 mV
Input Bias Current	0.05 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Gain Bandwidth	0.5 MHz
Minimum CMRR Range	80dB ~ 85dB
Supply Voltage	2V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	2 V
	expand all
Size-Length	10.16 mm
Size-Width	7.11 mm
Size-Height	4.95 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The CA3420EZ is a low supply voltage low input current single BiMOS Operational Amplifier combines PMOS transistors and bipolar transistors on a single monolithic chip. The CA3420 BiMOS op-amp features gate protected PMOS transistors in the input circuit to provide very high input impedance, very low input currents (less than 1pA). The internal bootstrapping network features unique guard-banding technique for reducing the doubling of leakage current for every 10°C increase in temperature. This operational amplifier is internally phase compensated to achieve stable operation in the unity gain follower configuration. Additionally, it has access terminals for a supplementary external capacitor if additional frequency roll-off is desired. Terminals are also provided for use in applications requiring input offset voltage nulling. The use of PMOS in the input stage results in common mode input voltage capability down to 0.45V below the negative supply terminal.
