CQ82C55AZ ,Interface IC, Interface Controller - Intersil
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
90 points
-
Part NoCQ82C55AZ
-
ManufacturerIntersil
-
ChipWorker Part#CW69636140
-
CategoryInterface IC, Interface Controller
-
PackageMQFP-44
-
DescriptionIC, I/O EXPANDER; Chip Configuration:8Bit; Bus Frequency:8MHz; IC Interface Type:CMOS; Supply Voltage Min:4.5V; Supply Voltage Max:5.5V; Interface Case Style:MQFP; No. of Pins:44; No. of I/Os:24; Packaging:Each; MSL:- ;RoHS Compliant: Yes
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие1 pcs In Stock
-
Estimated Price$ 0.01
