H11A1 - VISHAY

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

H11A1
Manufacturer

VISHAY
ChipWorker Part#

CW11933593
Category

Optocoupler, Optoisolator
Package

DIP-6
Description

H11A1 Series Single Channel 30V 5300Vrms Phototransistor Optocoupler - DIP-6
Documentation

Datasheet

H11A1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

H11A1 Specifications

Attribute	Attribute Value

Part Number	H11A1
Manufacturer	VISHAY
ChipWorker Part#	CW11933593
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	6 Pin
Case/Package	DIP-6
Voltage Rating (DC)	1.10 V
Output Voltage	70.0 V
Number of Channels	1 Channel
Number of Positions	6 Position
Forward Voltage	1.5 V
Input Current	60.0 mA
Power Dissipation	0.15 W
Rise Time	3 µs
Isolation Voltage	5300 Vrms
Forward Current	60 mA
Input Current (Min)	60 mA
Reverse Breakdown Voltage	6 V
Maximum Forward Voltage (Max)	1.5 V
Forward Current (Max)	60 mA
Fall Time	3 µs
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	150 mW
	expand all
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

The H11A1 is a Phototransistor Output Optocoupler with base connection and consists of gallium arsenide infrared LED and a silicon NPN phototransistor. The isolation performance is accomplished through Vishay double melding isolation manufacturing process.
