H11D1TM ,Optocoupler, Optoisolator - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

41 points

Part No

H11D1TM
Manufacturer

Fairchild
ChipWorker Part#

CW253083103
Category

Optocoupler, Optoisolator
Package

DIP-6
Description

Optocoupler DC-IN 1CH Transistor With Base DC-OUT 6Pin PDIP White Bulk
Documentation

Datasheet
Ships from

Moscow
Наличие

1330 pcs In Stock
Estimated Price

Price on Request

Buy H11D1TM

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

H11D1TM Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

H11D1TM Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	H11D1TM
Manufacturer	Fairchild
ChipWorker Part#	CW253083103
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	6 Pin
Case/Package	DIP-6
Number of Channels	1 Channel
Forward Voltage	1.15 V
Isolation Voltage	4170 Vrms
Forward Current	80 mA
Output Voltage (Max)	300 V
	expand all
Operating Temperature	-40℃ ~ 100℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

General Description
The 4N38M, H11DXM and MOC8204M are phototransistor-type optically coupled optoisolators. A gallium arsenide infrared emitting diode is coupled with a high voltage NPN silicon phototransistor. The device is supplied in a standard plastic six-pin dual-in-line package.
Features
■ High voltage:
– MOC8204M, BVCER = 400V
– H11D1M, H11D2M, BVCER = 300V
– H11D3M, BVCER = 200V
■ High isolation voltage:
– 7500 VAC peak, 1 second
■ Underwriters Laboratory (UL) recognized File # E90700, Volume 2
■ IEC 60747-5-2 approved (ordering option V)
Applications
■ Power supply regulators
■ Digital logic inputs
■ Microprocessor inputs
■ Appliance sensor systems
■ Industrial controls
