ICL7660ACPAZ ,Voltage Regulator - Intersil

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

124 points

Part No

ICL7660ACPAZ
Manufacturer

Intersil
ChipWorker Part#

CW56139200
Category

Voltage Regulator
Package

DIP-8
Description

INTERSIL ICL7660ACPAZ DC-DC Adjustable Charge Pump Voltage Converter, 1.5V to 12V in, -12V to -1.5V/45mA out, DIP-8
Documentation

Datasheet
Ships from

Moscow
Наличие

430 pcs In Stock
Estimated Price

$ 0.44

Buy ICL7660ACPAZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ICL7660ACPAZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ICL7660ACPAZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ICL7660ACPAZ
Manufacturer	Intersil
ChipWorker Part#	CW56139200
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Frequency	10.0 kHz
Supply Voltage (DC)	1.50V (min)
Number of Outputs	1 Output
Output Voltage	-12.0 V (min)
Output Current	45 mA
Supply Current	0.16 mA
Number of Positions	8 Position
Switching Frequency	3 kHz
Input Voltage (Max)	12 V
Input Voltage (Min)	1.5 V
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Input Voltage	1.5.12 V
	expand all
Size-Length	10.16 mm
Size-Width	7.11 mm
Size-Height	4.95 mm
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ICL7660ACPAZ is a CMOS Voltage Converter. The ICL7660A monolithic CMOS power supply circuits which offer unique performance advantages over previously available devices. The ICL7660 performs supply voltage conversions from positive to negative for an input range of +1.5 to +10.0V resulting in complementary output voltages of -1.5 to -10.0V and the ICL7660A does the same conversions with an input range of +1.5 to +12.0V resulting in complementary output voltages of -1.5 to -12.0V. Only 2 noncritical external capacitors are needed for the charge pump and charge reservoir functions. The ICL7660A can also be connected to function as voltage doublers and will generate output voltages up to +18.6V with a +10V input.
Simple conversion of +5V logic supply to ±5V supplies
Simple voltage multiplication VOUT = (-) nVIN
Typical open circuit voltage conversion efficiency 99.9%
Typical power efficiency 98%
Easy to use, requires only 2 external non-critical
Passive components
No external diode over full temperature and voltage range
ESD sensitive device, take proper precaution while handling the device.
