Part No

IR21271PBF
Manufacturer

Infineon
ChipWorker Part#

CW40100135
Category

FET Driver
Package

PDIP-8
Description

MOSFET DRVR 600V 0.5A 1Out Hi Side Non-Inv 8Pin PDIP
Documentation

Datasheet

IR21271PBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IR21271PBF Specifications

Attribute	Attribute Value

Part Number	IR21271PBF
Manufacturer	Infineon
ChipWorker Part#	CW40100135
Category	FET Driver
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	10.0V (min)
Rise/Fall Time	80ns, 40ns
Number of Outputs	1 Output
Power Dissipation	1000 mW
Fall Time (Max)	65 ns
Fall Time (Max)	130 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1000 mW
Supply Voltage	9V ~ 20V
	expand all
Size-Length	10.92 mm
Size-Width	7.11 mm
Size-Height	5.33 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Summary of Features:
Floating channel designed for bootstrap operation
Fully operational to +600 V
Tolerant to negative transient voltage dV/dt immune
Application - specific gate drive range: 9 to 20 V (IR21271) and 12 to 20 V (IR2127 Output out of phase with input (IR2128 )
