LSZ51C - Honeywell

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

LSZ51C
Manufacturer

Honeywell
ChipWorker Part#

CW6087075
Category

Switch Accessory
Package

-
Description

MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, 38mm [1.5in] Fixed Length Roller Lever with Ø 19mm x 6,35mm [0.75in x 0.25in] Nylon Roller, Back Roller Mounting
Documentation

Datasheet

LSZ51C Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

LSZ51C Specifications

Attribute	Attribute Value

Part Number	LSZ51C
Manufacturer	Honeywell
ChipWorker Part#	CW6087075
Category	Switch Accessory
Documentation	Datasheet
Case/Package	-
Actuator Type	Roller Lever
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
	expand all
Size-Length	19 mm
Size-Width	18.7 mm
Size-Height	26.6 mm
Size-Diameter	19.0 mm
Material	Nylon
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HTS Code	8538908080
ECCN Code	EAR99

Product Description

Lever, Nylon Material, 0.75 in. Diameter, 0.25 in. Width
The HDLS limit switches are built to last and are designed for easy application installation. Its unique all-metal drive train provides consistent operating characteristics and lasts longer than drive trains with plastic parts. The HDLS offers sintered bronze bearings on 303 stainless steel operating shafts for a long, reliable mechanical life. Whether single or double pole, plug in or non-plug in, they all offer the same actuator lever tracking dimensions for the ultimate in design flexibility. All this is packaged in a rugged corrosion-resistant zinc head and body that is phosphate treated and epoxy finished.
** Features**
* Wide Variety of Operating Heads
* Captive Head and Body Screws
* One Piece Flat Base to Receptacle Seal Gasket
** Specifications**
* UL Recognized, File #E37138
* CSA Certified, File #LR57326
* Sealing: NEMA 1, 3, 4, 6, 13, 4X, 6P
* CE Certified
