MC34167TG ,Voltage Regulator - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

92 points

Part No

MC34167TG
Manufacturer

ON Semiconductor
ChipWorker Part#

CW9901740
Category

Voltage Regulator
Package

TO-220-5
Description

Conv DC-DC 7.5V to 40V Non-Inv/Inv/Step Up/Step Down Single-Out 5.05V 5A Automotive 5Pin(5+Tab) TO-220 Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

10 pcs In Stock
Estimated Price

$ 3.16

Buy MC34167TG
