NMK1205SC - muRata

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

NMK1205SC
Manufacturer

muRata
ChipWorker Part#

CW79785885
Category

DC to DC Converter, DC/DC Converter
Package

SIP-7
Description

Module DC-DC 12Vin 2Out 5V/-5V 0.2A/-0.2A 2W 5Pin SIP Tube
Documentation

Datasheet

NMK1205SC Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

NMK1205SC Specifications

Attribute	Attribute Value

Part Number	NMK1205SC
Manufacturer	muRata
ChipWorker Part#	CW79785885
Category	DC to DC Converter, DC/DC Converter
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	SIP-7
Supply Voltage (DC)	12.0 V
Power Rating	2 W
Number of Outputs	2 Output
Input Voltage (DC)	10.8V ~ 13.2V
Output Voltage	±5 VDC
Output Current	200 mA
Flammability Rating	UL 94 V-0
Output Power	2 W
Isolation Voltage	3 kV
Input Voltage (Max)	13.2 V
Input Voltage (Min)	10.8 V
Input Voltage (DC Max)	13.2 V
Input Voltage (DC Min)	10.8 v
Output Current (Max)	200mA, 200mA
Input Power (Max)	2 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	10.8V ~ 13.2V
	expand all
Size-Length	19.5 mm
Size-Width	7.65 mm
Size-Height	10.15 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

Provide the ability to switch between voltages by using this step down NMK1205SC DC to DC converter and switching regulator module. It has a voltage of 5|-5 V. This part has a temperature range of -40 °C to 85 °C. This device comes in tube packaging.
