PDTC143ZT - NXP

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

PDTC143ZT
Manufacturer

NXP
ChipWorker Part#

CW42479366
Category

BJT Transistor, BJT
Package

SOT-23
Description

TO-236AB NPN 50V 100mA
Documentation

Datasheet

PDTC143ZT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

PDTC143ZT Specifications

Attribute	Attribute Value

Part Number	PDTC143ZT
Manufacturer	NXP
ChipWorker Part#	CW42479366
Category	BJT Transistor, BJT
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23
Number of Positions	3 Position
Polarity	NPN
Power Dissipation	250 mW
Breakdown Voltage (Collector to Emitter)	50 V
Continuous Collector Current	100mA
hFE Min	100
DC Current Gain (hFE)	100
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
	expand all
Size-Length	3 mm
Size-Width	1.4 mm
Size-Height	1 mm
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The PDTC143ZT is a 4.7 to 47kR NPN Resistor Equipped Transistor (RET) in a small surface-mount plastic package.
Reduces component count
Built-in bias resistors
Reduces pick and place costs
Simplifies circuit design
AEC-Q101 qualified
PNP complement is PDTA143ZT
18 Marking code
