PIC18LF4550-I/PT ,Microcontroller, MCU IC - Microchip
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
129 points
-
Part NoPIC18LF4550-I/PT
-
ManufacturerMicrochip
-
ChipWorker Part#CW740711
-
CategoryMicrocontroller, MCU IC
-
PackageTQFP-44
-
DescriptionMCU 8Bit PIC18 PIC RISC 32KB Flash 2.5V/3.3V/5V 44Pin TQFP Tray
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие1 pcs In Stock
-
Estimated Price$ 11
Payment Methods and Delivery
{{ estimate }}
Buy PIC18LF4550-I/PT
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
PIC18LF4550-I/PT Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
PIC18LF4550-I/PT Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | PIC18LF4550-I/PT | |
| Manufacturer | Microchip | |
| ChipWorker Part# | CW740711 | |
| Category | Microcontroller, MCU IC | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 44 Pin | |
| Case/Package | TQFP-44 | |
| Frequency | 48 MHz | |
| Supply Voltage (DC) | 5.00 V, 5.50 V (max) | |
| Operating Voltage | 2V ~ 5.5V | |
| Number of Positions | 44 Position | |
| Clock Speed | 48.0 MHz | |
| RAM Memory Size | 2 KB | |
| Number of Bits | 8 Bit | |
| Power Dissipation | 1000 mW | |
| FLASH Memory Size | 32 KB | |
| Number of I/O Pins | 35 IO | |
| Access Time | 48.0 µs | |
| Core Architecture | PIC | |
| Memory Size | 32000 B | |
| Core Sub-Architecture | PIC18 | |
| Number of ADCs | 1 ADC | |
| Number of Inputs and Outputs | 35 Input IO | |
| Operating Temperature (Max) | 85 ℃ | |
| Operating Temperature (Min) | -40 ℃ | |
| Power Dissipation (Max) | 1000 mW | |
| Supply Voltage | 3V ~ 5.5V | |
| Supply Voltage (Max) | 5.5 V | |
| Supply Voltage (Min) | 2 V | |
| expand all | ||
| Size-Length | 10 mm | |
| Size-Width | 10 mm | |
| Size-Height | 1.05 mm | |
| Operating Temperature | -40℃ ~ 85℃ | |
| Product Lifecycle Status | Unknown | |
| Packaging | Tray | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| REACH SVHC Compliance Edition | 2015/12/17 | |
| HTS Code | 8542310001 | |
| ECCN Code | 3A991.a.2 | |
| HK STC License | NLR |
Similar & Replacement Parts
Similar products
Product Description
- The PIC18LF4550-I/PT is a high-performance enhanced flash USB Microcontroller with nanoWatt technology. Ideal for low power (nanoWatt) and connectivity applications that benefit from the availability of three serial ports of FS-USB(12Mbps), I²C™ and SPI™ (up to 10Mbps) and an asynchronous (LIN capable) serial port (EUSART). Large amounts of RAM memory for buffering and Enhanced Flash program memory make it ideal for embedded control and monitoring applications that require periodic connection with a (legacy free) personal computer via USB for data upload/download or firmware updates. The PIC18F4550 family introduces design enhancements that make this microcontroller a logical choice for many high-performance and power sensitive applications. The PIC18F4550 incorporate a different oscillator and microcontroller clock system than previous PIC18F devices.
- Low speed (1.5Mbps) and full speed (12Mbps)
- Supports control, interrupt, isochronous and bulk transfers
- Supports up to 32 endpoints (16 bidirectional)
- 1kB Dual access RAM for USB
- On-chip USB transceiver with on-chip voltage regulator
- Power-managed mode - Two-speed oscillator start-up
- Flexible oscillator structure - Four crystal modes, including high-precision PLL for USB
- Peripheral - Enhanced USART module and enhanced capture/compare/PWM (ECCP) module
- Flash/data EEPROM retention of >40 years
- Self-programmable under software control
- 8 x 8 Single-cycle hardware multiplier
- In-Circuit Debug (ICD) via two pins
- ESD sensitive device, take proper precaution while handling the device.
