Part NoST7FLITE39F2M6
-
ManufacturerST Microelectronics
-
ChipWorker Part#CW11464051
-
CategoryMicrocontroller, MCU IC
-
PackageSOIC-20
-
DescriptionSTMICROELECTRONICS ST7FLITE39F2M6 8Bit Microcontroller, Single Voltage Flash, ST7FLITE3x, 8MHz, 8KB, 384Byte, 20Pins, SOIC
-
DocumentationDatasheet
