STPM33TR ,Specialty Application IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

89 points

Part No

STPM33TR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW11475656
Category

Specialty Application IC
Package

QFN-32
Description

STPM33 Series 3.3V 4mA 3.6kHz Single Phase Metering IC - QFN-32
Documentation

Datasheet
Ships from

Moscow
Наличие

5800 pcs In Stock
Estimated Price

$ 2.07

Buy STPM33TR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STPM33TR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STPM33TR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STPM33TR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW11475656
Category	Specialty Application IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	QFN-32
Supply Voltage (DC)	2.95V (min)
Supply Current	4 mA
Number of Channels	2 Channel
Number of Positions	32 Position
Number of ADCs	4 ADC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	0.1 %
Supply Voltage	2.95V ~ 3.65V
Supply Voltage (Max)	3.65 V
Supply Voltage (Min)	2.95 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The STPM33TR is a high accuracy Analog Front End (AFE) for DC and AC energy measurement, offering high accuracy down to extremely low current typical of home appliances in stand-by. A full set of on-board features provides high system integration and enable on-chip power quality monitoring. The device has up to 4 independent 24 bits 2nd order ∑Δ ADC with PGA. The device has integrated DSP for "turn-key" energy parameters calculations. Built-in twin independently temperature compensated voltage references and double LED output programmable for active and reactive energy pulses generation.
Applicable to class 0.2m
<0.1% Active power accuracy over a dynamic range of 5000:1
4kHz Bandwidth
Very fast single point calibration
AC and DC measurement
Multiple sensors support - Shunt, current transformer, Rogowsky coils
Multiple host interfaces 5 and 3 wires SPI, UART
I,V bit stream available to host controller for customer own processing
Case removal and Neutral Anti-tamper detection
Exceeds 50-60Hz EN 50470-x, IEC 62053-2x, ANSI12.2x
