TB62726AFNA - Toshiba

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

17 points

Part No

TB62726AFNA
Manufacturer

Toshiba
ChipWorker Part#

CW486181590
Description

16Bit constant current LED driver with operating supply of 3.3V to 5V
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

Price on Request

Buy TB62726AFNA

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TB62726AFNA Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TB62726AFNA Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TB62726AFNA
Manufacturer	Toshiba
ChipWorker Part#	CW486181590
Documentation	Datasheet
	expand all
RoHS	RoHS Compliant

Similar & Replacement Parts

Similar products

PI3B16245AE

Pericom Semiconductor

Pericom Semiconductor

736 шт.

Product Description

16-bit constant current LED driver with operation supply of 3.3V to 5V
The TB62726AFNA is comprised of constant-current drivers designed for LEDs and LED displays. The output current value can be set using an external resistor. As a result, all outputs will have virtually the same current levels. This driver incorporates a 16-bit constant-current output, a 16-bit shift register, a 16-bit latch and a gate circuit. These drivers have been designed using the Bi-CMOS process.
Feature
* Output current capability and the number of output: 90 mA x 16 outputs
* Constant current range : 2 to 90 mA
* Application output voltage :
0.7V (output current 2 to 80mA)
0.4V (output current 2 to 40mA)
* For anode common LED
* Input signal voltage level :
3.3V-5.0V CMOS level (schmitt trigger input)
* Power supply voltage range VDD=3.0 to 5.5V
* Muximum output terminal voltage 17V
* Serial and parallel data transfer rate 20 MHz (min., Cascade Connection)
* Operation temperature range topr = -40 to 85 degrees
* Package : P-SSOP24-150-0.635
