TOP242PN ,AC to DC Converter, AC/DC Power Module - Power Integrations

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

101 points

Part No

TOP242PN
Manufacturer

Power Integrations
ChipWorker Part#

CW5206638
Category

AC to DC Converter, AC/DC Power Module
Package

DIP-8
Description

AC-DC Off-Line Switcher IC, TOPSwitch-GX, Flyback, 85VAC - 265VAC, 132kHz, 720mA out, 15W, DIP-8
Documentation

Datasheet
Ships from

Moscow
Наличие

9275 pcs In Stock
Estimated Price

$ 0.85

Buy TOP242PN

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TOP242PN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TOP242PN Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TOP242PN
Manufacturer	Power Integrations
ChipWorker Part#	CW5206638
Category	AC to DC Converter, AC/DC Power Module
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Frequency	132 kHz
Supply Voltage (DC)	374V (max)
Power Rating	15 W
Number of Outputs	1 Output
Input Voltage (DC)	265 V
Output Voltage	700 V
Output Current	720 mA
Breakdown Voltage	700 V
Supply Current	1.60 mA
Number of Positions	8 Position
Output Power	10 W
Switching Frequency	66kHz ~ 132kHz
Duty Cycle	66.5 %
Input Voltage (AC Max)	265 v
Input Voltage (AC Min)	85 v
Maximum Duty Cycle	83 %
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	85.265 V
	expand all
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC

Similar & Replacement Parts

Similar products

Product Description

The TOP242PN is a TOPSwitch-GX Integrated Off-line Switcher IC flyback supply provides 4 outputs, delivering 7W from a 230VAC ±15% input. Resistor R7 programs the internal TOP242PN current limit to 78% of nominal, just above the level needed for full load at low line. This feature allows a more continuous transformer design for better efficiency and cross-regulation, without requiring a larger core size. Resistor R12, C10 and L2 filter conducted EMI; R12 is a flameproof fusible type, also functioning as a fuse. For lower cost, if the supply does not have to meet conducted EMI with the output connected to earth ground, the common mode choke can be replaced with a π filter. A Zener clamp (D11 and VR1) was selected over an RCD clamp to minimize zero load consumption.
<0.5W Input power at zero load
Low component count design occupies 80 x 30 x 16mm
Integrated soft-start reduces start-up component stresses
Extended power range for higher power applications
Eliminate or reduce cost of external components
Externally programmable accurate current limit
No turn off glitches line under-voltage (UV) detection
Line over voltage (OV) shutdown extends line surge limit
132kHz Frequency reduces transformer/power supply size
Hysteretic thermal shutdown for automatic fault recovery
Large thermal hysteresis prevents PC board overheating
