Part No

TPA2000D1PW
Manufacturer

TI
ChipWorker Part#

CW7131604
Category

Audio Amplifier IC
Package

TSSOP-16
Description

TEXAS INSTRUMENTS TPA2000D1PW Audio Power Amplifier, D, 1Channel, 2W, 2.7V to 5.5V, TSSOP, 16Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 2.99

Buy TPA2000D1PW

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors
